Specifications and Operation
|
|
|
Staber Washing Machine available in:
- Standard
White
- White with
with Stainless Steel Base
- Ivy Green
- Jet Black
- Ocean Blue
- Ruby Red
- Brushed Stainless Steel Cabinet
View Stainless Steel model
 |
Time breakdown per maximum load of clothes
|
| Prewash |
|
5 minutes plus fill time |
| Wash time |
|
Up to 15 minutes plus fill time |
| Rinse time |
|
Two 5 minute rinses plus fill time |
| Spin time |
|
5 minutes |
| Decake/Index |
|
3 minutes |
|
Water use per load in each
cycle
|
| Washer Setting |
Normal
|
Low
|
|
Normal
|
16.5 GAL
|
12 GAL
|
|
Permanent Press
|
16.5 GAL
|
12 GAL
|
|
Delicate
|
16.5 GAL
|
12 GAL
|
|
Pre-Wash & Normal
|
22 GAL
|
|
Normal Hot to Cold
usage
This is directly related to the temperature and water level selection
|
|
Water Level / Temp |
Hot |
Cold |
| Normal / Hot |
5.5 GAL |
11 |
| Normal / Warm |
2.7 GAL |
13.7 |
| Normal / Cold |
|
16.5 |
. Clothes capacity per load: 18 lb.
. Detergent use per normal load: 1 oz. Max
. Watts of electricity per
load: 110-150 watt hours
. Motor
type: Universal/digital-electronically controlled motor
. Motor h.p. rating: Less than �
. Motor amps being drawn in wash: ~ 4 to ~ 5 amps
. Motor amps being drawn during spin: ~ 2
amps
. Spin cycle rpm:~ 400 (delicate & perm) ~ 600 up
to 850 (normal)
. Extraction force: ~
200 g's
. Type of drain cycle: Self cleaning
electric water pump
. The inner drum
dia: ~ 23" giving ~ 2 cubic feet of usable volume
. Inner & outer tub material: Stainless steel
. Automatic dispensers: Prewash,
detergent, bleach, softener
DIMENSIONS AND WEIGHT
. Size of machine in
inches:
. Width = 27 Depth = 26 Back Height = 42 Height with door up = 55
. Machine weight: Net = 175 lbs. Shipping = 240
lbs.
 |
Maintenance and Repair
|
The unit
comes with a manufacturer's warranty on parts. Staber washers are designed to be
serviced by the customer. Total front access and simple design allows the
customer to maintain and service their machine without having to pay large
repair bills. Staber Industries offers guidance on do-it-yourself maintenance
and repair. All replacement parts are shipped factory direct by UPS or FedEx to
the customer.
|
|
|
|
|
|
|
